Hello,

on freedom-ui, i would like to add a custom sidebar component, to handle phone calls notes.
When a call is over, the sidebar would open to let the user enter some notes about it.

So far i made an angular app to test, according to this guide :
https://academy.creatio.com/docs/8.x/dev/development-on-creatio-platfor…


Now that my angular app is ready to upload, it seems i can't do it because our creatio development instance is not deployed on-site : the system cannot be used with file system development.
(https://academy.creatio.com/docs/8.x/dev/development-on-creatio-platfor…)


Is there any workaround for this ?

Should i try to make it in a different way ?


Best regards.
Patrice

Like 0

Like

0 comments
Show all comments

I have a homepage that uses the Tabbed Page with progress bar template called "Dashboard Homepage". When I try setting up a user workplace and setting it as the homepage, it gets stuck loading, and never shows the dashboard. I've tested this with a brand new template page, and get the same issue.

When I set it to a page that uses the list template, it works perfectly fine. I imagine this has something to do with the functionality a page offers, but am awfully confused.

Any reason as to why I can't just set a Tabbed Page with Progress Bar as the homepage of my app?

Like 0

Like

0 comments
Show all comments

Hi,

is there any documentation on how to use the File param type in a business process? I wasn't able to find any.

I have a use case where i have to save a file as an attachment to an entity, starting from a base64 rappresentation of the file. I would like to accomplish this task with the least amount of coding. What i envisioned is a business process with a script task that converts the base64 to a File param. Then a process file shape that saves the File param. Sadly i'm dead in the water on how to implement this scenario because i have no idea on how to use File param type. I can't even understand what .Net/Terrasoft type it is. Do you have any suggestion?

Like 0

Like

1 comments

Hello,

Please specify if you have checked the available basic functionality meant for processing files within business processes - the "Process File" element? If so, could you describe why exactly does this option not work for you?

https://academy.creatio.com/docs/8.x/no-code-customization/bpm-tools/pr…

Show all comments

Hello,

We are trying to set up telephony integration.
We have licenses : asterisk connector for creatio user cloud . We have modified SysMsgServerNode and SysMsgLib ( value = Asterisk 13/16/18 (AMI) telephony integration library)
We have also set up CMS and Asterisk.
At telephony we see a message : Phone server connection is unavailable. Please ensure that connection parameters are set up and that the server is online

Like 0

Like

0 comments
Show all comments

Hello, i am using a free trial version of creatio this time, now there is a problem that i am trying to solve

you see what i want and what is currently shown through images is what i want, where one field changes the rest with the same name changes, but im also trying to add in a handler for this field

Number condition, where if the number condition is more than 2Billion then the Testing Condition of more than expansion panel would appear, for now i set it so that the checkbox would be the condition of wether or not the expansion panel would appear, now i did the handle like so...

then the weirdest thing happen, these fields do not update the rest when i change one of them

so does anyone have any clue of why this is happening since i like to use duplicate fields and the handler to detect changes

Like 0

Like

2 comments

Hello Michael.

Sorry, but the task is not clear. Can you please use 3 fields and explain the actual result and the expected result. And also what is the data type for each field. Also there is a possibility that your logic is not working in case you are using Integer data type columns where the maximum value possible is 2,147,483,647. And also there is no logic in the screenshots that could explain why the rest columns should change the value.

Oleg Drobina,

so basically i want 3 fields using the same UsrCode so that when i type in on 1 field the rest of the fields gets auto-filled by the one that i edited, this works normally, however when i add in a handler to scan the fields in the JS code to add a more than condition based on another field that has nothing to do on the 3 fields using the same UsrCode, it broke the duplicated fields

picture this,

in this image there are several fields however they have the same UsrCode by their name, so if i change the "Nama User" field on the first expansion panel then the rest of the fields with the title "Nama User" gets changed, now when i add in a handler on another tab(the "Nama User" field is on Testing Tab)

like if the Number Condition is more than 2Billion then mark true for the visibility of the "Testing Condition of more than" expansion panel, but when i add in the handler in the Javascript like so

it broke the duplicate fields in the testing tab, so the "Nama User" Field does not get updated when i make a change on one of the fields

Show all comments

Is this method for adding current date to a word report still valid? https://academy.creatio.com/docs/8.x/dev/development-on-creatio-platform/8.1/platform-customization/classic-ui/ms-word/examples/create-ms-word-report-custom-macros#title-15703-2  After compiling Creatio can't find refs to IExpressionConverter or ExpressionConverterAttribute.



Regards,

Michael

Like 0

Like

3 comments
Best reply

Michael Lim,

For the Date macro, it needs to be [#Date#], not [#DATE#]

I've also tried this method but when the report prints the field is empty. I'm on version 8.2.3.   https://academy.creatio.com/docs/developer/application_components/reports/ms_word/overview#title-1371-3





Version 8+ documentation looks similar in structure, it just has less information for the setup https://academy.creatio.com/docs/8.x/dev/development-on-creatio-platform/platform-customization/freedom-ui/ms-word/references/basic-macros



Regard,

Michael

Michael Lim,

For the Date macro, it needs to be [#Date#], not [#DATE#]

Ryan Farley,

Thank you Ryan. I got the formatting to using Created on[#Date|MM/dd/yyyy#]

Show all comments

Hello all,

Is it possible in Freedom UI to add folders to sections other than Contacts? We need to enable static folders in the Knowledge Base.

Like 0

Like

0 comments
Show all comments

Hi Creatio Community,

We're encountering a puzzling issue on a Freedom UI List Page (specifically, our Invoices_ListPage) when trying to run a business process (IWVoid_API_POST) using a custom JavaScript handler. The goal is to test the business process by explicitly passing a hardcoded InvoiceId, as requested for a specific testing scenario where the button is not on the individual record's form page.

Our Setup:

  1. The Button (Menu Item on List Page's ActionButton):

    We've added a crt.MenuItem to the ActionButton on our Invoices_ListPage. This menu item is intended for testing and is configured to trigger a custom handler:

    JSON



    // In viewConfigDiff of Invoices_ListPage.js
    {
        "operation": "insert",
        "name": "TargetVoidButton", //
        "values": {
            "type": "crt.MenuItem",
            "caption": "Test Void BP (Hardcoded ID)",
            "icon": "debug-icon",
            "visible": true,
            "clicked": {
                "request": "crt.HandleButtonClickRequest",
                "params": {
                    "buttonName": "RunTargetVoidProcessHandler"
                }
            }
        },
        "parentName": "ActionButton",
        "propertyName": "menuItems",
        "index": 3
    }
  2. The Handler (in handlers array of Invoices_ListPage.js):

    This handler is designed to run the IWVoid_API_POST process with a specific, hardcoded InvoiceId.

    JavaScript



    // In handlers array of Invoices_ListPage.js
    {
        request: "crt.HandleButtonClickRequest",
        handler: async (request, next) => {
            if (request.buttonName === "RunTargetVoidProcessHandler") {
                console.log("RunTargetVoidProcessHandler triggered.");
                Terrasoft.showInformation("Test: Running process with hardcoded ID. Check console.");

                const processName = "IWVoid_API_POST";
                const hardcodedInvoiceIdForTest = "3c2b6d9f-4c1e-4364-99f2-53956562b606";
                const parameterNameInProcess = "InvoiceId";

                console.log(`Test: Attempting to run BP '<span class="math-inline">\{processName\}' with EXPLICIT HARDCODED ID '</span>{hardcodedInvoiceIdForTest}' for parameter '${parameterNameInProcess}'.`);

                try {
                    const response = await request.$context.executeRequest({
                        type: "crt.RunBusinessProcessRequest",
                        params: {
                            processName: processName,
                            processParameters: {
                                [parameterNameInProcess]: hardcodedInvoiceIdForTest
                            },
                            saveAtProcessStart: false,
                            showNotification: true
                        }
                    });

                    console.log("Test: BP execution request completed. Response:", response);

                    if (response && response.success === true && response.processId && response.processId !== '00000000-0000-0000-0000-000000000000') {
                        const successMsg = `Test: BP '${processName}' (ID: ${response.processId}) initiated. Check Process Log.`;
                        console.log(successMsg);
                        request.$context.showInformationDialog?.(successMsg);
                    } else {
                        let errorMsg = `Test: Failed to start BP '${processName}'.`;
                        let serverDetails = (response && response.errorInfo && response.errorInfo.message) ? response.errorInfo.message : "Details unavailable or process not found (zero ID / success:false).";
                        errorMsg += ` ${serverDetails}`;
                        console.error(errorMsg, "Full response:", response);
                        request.$context.showErrorDialog?.(errorMsg);
                    }
                } catch (error) {
                    console.error(`Test: Exception for BP '${processName}':`, error);
                    let exceptionMsg = (error instanceof Error && error.message) ? error.message : "Client-side exception.";
                    if (error.errorInfo && error.errorInfo.message) {
                        exceptionMsg = error.errorInfo.message;
                    }
                    request.$context.showErrorDialog?.(`Test: Error triggering BP: ${exceptionMsg}`);
                }
                return;
            }
            return next?.handle(request);
        }
    }

The Problem:

When we click the "Test Void BP (Hardcoded ID)" menu item, the handler triggers, and the client-side logs show the crt.RunBusinessProcessRequest is being prepared correctly with processName: "IWVoid_API_POST" and the hardcoded InvoiceId.

However, the server responds with:

{
  processId: '00000000-0000-0000-0000-000000000000',
  processStatus: 0,
  resultParameterValues: null,
  executionData: null,
  success: false,
  errorInfo: {
    errorCode: "ItemNotFoundException",
    message: "Item process schema \"\" not found.", // Note the empty quotes for schema name
    stackTrace: null
  }
}

The key error is <strong>Item process schema "" not found.</strong>

What We've Tried:

  • Confirmed the schematic name (Code) of our business process is indeed IWVoid_API_POST.
  • Confirmed the input parameter in the BP designed to take the ID is named InvoiceId.
  • Repeatedly saved, compiled, and published the IWVoid_API_POST business process and ensured it's marked as "Active."
  • Checked the package containing the process for any errors and recompiled the package.
  • Performed thorough browser cache clearing and hard refreshes (Ctrl+F5).
  • We also have another menu item on the same list page ("VoidInvoice") that uses a declarative crt.RunBusinessProcessRequest with processRunType: "ForTheSelectedRecords" and parameterMappings: { "InvoiceId": "Id" }. When a record is selected and this menu item is clicked, it successfully starts the <strong>IWVoid_API_POST</strong> process (verified in Creatio Process Log with a non-zero instance ID). This makes the current error even more puzzling.

Our Questions for the Community:

  1. Why would the ProcessEngineService report Item process schema "" not found (with empty quotes for the schema name) when the processName: "IWVoid_API_POST" is explicitly and correctly provided in the params of crt.RunBusinessProcessRequest from our custom handler?
  2. Is there any known difference in how process names are resolved or how schemas are looked up by the server when crt.RunBusinessProcessRequest is invoked programmatically from a handler with processParameters explicitly set (using a hardcoded ID), versus when it's invoked declaratively with processRunType: "ForTheSelectedRecords" or processRunType: "ForTheSelectedPage"?
  3. Are there any deeper caching mechanisms (server-side, metadata) or specific registration steps for business process schemas that we might be missing, which could lead to this behavior only for the explicit parameter call?
  4. Has anyone encountered a similar situation where a process is findable/runnable via one SDK invocation method (declarative, context-based) but not another (programmatic handler, explicit parameters) from the same Freedom UI page type?

We are unable to access detailed server-side application logs for this specific environment at the moment, which is hampering deeper diagnosis from our end.

Any insights, suggestions, or similar experiences would be greatly appreciated!

Thank you!

Like 0

Like

1 comments

Hi Andrew,

The behavior you described where the system responds with Item process schema "" not found despite providing the correct process name can occur when certain required parameters are missing during the execution of a business process from a handler. Specifically, when using crt.RunBusinessProcessRequest from a crt.HandleButtonClickRequest handler, the backend expects additional context that is typically provided automatically during declarative invocations.

To ensure that the process schema is correctly identified and executed, it is important to explicitly include the processRunType, the recordIdProcessParameterName. These parameters provide the necessary linkage between the UI context and the process runtime.

Below is an example of a working implementation where a business process is successfully launched from a button on a Freedom UI page. The button configuration and handler explicitly define all required fields:

Button configuration:
{
 "operation": "insert",
 "name": "Button_7y0uys4",
 "values": {
   "layoutConfig": {
     "column": 1,
     "row": 2,
     "colSpan": 1,
     "rowSpan": 1
   },
   "type": "crt.Button",
   "caption": "#ResourceString(Button_7y0uys4_caption)#",
   "color": "outline",
   "disabled": false,
   "size": "large",
   "iconPosition": "only-text",
   "visible": true,
   "clicked": {
     "request": "crt.HandleButtonClickRequest",
     "params": {
       "buttonName": "RunTestProcess",
       "processName": "UsrTestProcessInvoiceAdded",
       "processRunType": "ForTheSelectedPage",
       "recordIdProcessParameterName": "InvoiceId"
     }
   }
 },
 "parentName": "SideAreaProfileContainer",
 "propertyName": "items",
 "index": 1
}

Handler logic:
{
 request: "crt.HandleButtonClickRequest",
 handler: async (request, next) => {
   if (request.buttonName === "RunTestProcess") {
     const handlerChain = sdk.HandlerChainService.instance;
     const result = await handlerChain.process({
       type: "crt.RunBusinessProcessRequest",
       processName: "UsrTestProcessInvoiceAdded",
       processRunType: "ForTheSelectedPage",
       recordIdProcessParameterName: "InvoiceId",
       $context: request.$context
     });

     if (result.success) {
       console.log("The process was successfully executed!");
     } else {
       console.log("Exception: " + (result.errorInfo?.message || "Unknown issue"));
     }

     return;
   }
   return next?.handle(request);
 }
}

Answers to your questions:

1. Why would the ProcessEngineService report Item process schema "" not found (with empty quotes for the schema name) when the processName: "IWVoid_API_POST" is explicitly and correctly provided in the params of crt.RunBusinessProcessRequest from our custom handler?

- This usually happens if processRunType, recordIdProcessParameterName are not passed when triggering the process from a handler. These parameters are essential for correctly resolving the process schema in the runtime context.

2. Is there any known difference in how process names are resolved or how schemas are looked up by the server when crt.RunBusinessProcessRequest is invoked programmatically from a handler with processParameters explicitly set (using a hardcoded ID), versus when it's invoked declaratively with processRunType: "ForTheSelectedRecords" or processRunType: "ForTheSelectedPage"?

- Yes. In declarative calls, Creatio automatically adds all required metadata. In programmatic calls (handlers), this metadata must be passed manually, especially processRunType and recordIdProcessParameterName.

3. Are there any deeper caching mechanisms (server-side, metadata) or specific registration steps for business process schemas that we might be missing, which could lead to this behavior only for the explicit parameter call?

- In general, no special registration is required if the process is active and compiled. However, if the process was recently created or modified, reload the page and make sure that the changes in the process were saved.

4. Has anyone encountered a similar situation where a process is findable/runnable via one SDK invocation method (declarative, context-based) but not another (programmatic handler, explicit parameters) from the same Freedom UI page type?

- Yes, this can happen if the required context parameters are not included in the handler call. Declarative calls handle this automatically, whereas in handlers you must explicitly set them.

Show all comments

Hi there, here is a question I am not sure on how to set it up.

I want to add a user to our platform that can work with all the basic features but has limited access to our entire customer database. This means, he/she can only see the accounts and customers we put in a specified group.

How do I set this up? Or is there an example somewhere i can follow?

Like 0

Like

2 comments

Hello,

Can you please specify how exactly do you want to put customers and accounts in a specified group?

Hey @malika, the plan is to create  a separate section in our database for the our accounts that need to be managed by this role





Show all comments

Hi all,

i'm trying to setup a backend system able to send push notification to mobile app (not developed in creatio) through FCM rest API.

The first hurdle is obtaining a valid token to authenticate to notification api exposed by firebase. In order to obtain this token i do have to call another rest api passing a jwt token generated by me and signed by a private key downloaded from fcm.

I've got a code (pasted below) that manages to generate this encrypted token and it's working in visual studio. But if i try to use it in a script task i got the exception

'RSA' does not contain a definition for 'ImportPkcs8PrivateKey' and no accessible extension method 'ImportPkcs8PrivateKey' accepting a first argument of type 'RSA' could be found (are you missing a using directive or an assembly reference?)

As far as i know this exception is thrown if .net core being used is version 5 or below. But i'm on a demo instance with creation 8.2.0.4183 which should be already using net core 6 right?

Do you have any suggestion? (the flow is already configured to import System.Security.Cryptography)





--code--

   var now = DateTimeOffset.UtcNow.ToUnixTimeSeconds();
var header = new Dictionary
       {
           { "alg", "RS256" },
           { "typ", "JWT" }
       };
string headerJson = JsonConvert.SerializeObject(header);
string encodedHeader = Convert.ToBase64String(Encoding.UTF8.GetBytes(headerJson)).TrimEnd('=').Replace('+', '-').Replace('/', '_');

var payload = new Dictionary
       {
           { "iss", CLIENT_EMAIL },
           { "scope", SCOPE },
           { "aud", TOKEN_URI },
           { "iat", now },
           { "exp", now + 3600 }
       };
string payloadJson = JsonConvert.SerializeObject(payload);
string encodedPayload = Convert.ToBase64String(Encoding.UTF8.GetBytes(payloadJson)).TrimEnd('=').Replace('+', '-').Replace('/', '_');
string unsignedJwt = $"{encodedHeader}.{encodedPayload}";
byte[] dataBytes = Encoding.UTF8.GetBytes(unsignedJwt);

// Decode PEM -> PKCS#8 bytes
string cleanKey = PRIVATE_KEY
   .Replace("-----BEGIN PRIVATE KEY-----", "")
   .Replace("-----END PRIVATE KEY-----", "")
   .Replace("\\n", "\n")  // ← decodifica reale da stringa JSON
   .Trim();


byte[] privateKeyBytes = Convert.FromBase64String(cleanKey);

// Firma con RSA-SHA256
byte[] signature;
using (var rsa = RSA.Create())
{
   rsa.ImportPkcs8PrivateKey(privateKeyBytes, out _);
   signature = rsa.SignData(dataBytes, HashAlgorithmName.SHA256, RSASignaturePadding.Pkcs1);
}
string encodedSignature = Convert.ToBase64String(signature)
   .TrimEnd('=').Replace('+', '-').Replace('/', '_');

string jwt = $"{unsignedJwt}.{encodedSignature}";


return true;

Like 1

Like

1 comments
Best reply

Hi Roberto,

In the cloud-based demo version of Creatio (including your current instance), the Script Task in business processes runs under .NET Framework 4.7.2. This limitation is specific to the cloud version. If you run Creatio on-premises, it's possible to configure and run business logic under .NET Core instead.

As a result, the method ImportPkcs8PrivateKey() is not available in the cloud version. Other types like RSASignaturePadding, HashAlgorithmName, and RSA.Create() are also unavailable in this context.

Recommended Solution:
Move JWT generation to an external service
- Create a small Web API (in .NET 6 or above).
- Let it generate and return the signed JWT token.
- Call it from Creatio using HTTP request.

Hi Roberto,

In the cloud-based demo version of Creatio (including your current instance), the Script Task in business processes runs under .NET Framework 4.7.2. This limitation is specific to the cloud version. If you run Creatio on-premises, it's possible to configure and run business logic under .NET Core instead.

As a result, the method ImportPkcs8PrivateKey() is not available in the cloud version. Other types like RSASignaturePadding, HashAlgorithmName, and RSA.Create() are also unavailable in this context.

Recommended Solution:
Move JWT generation to an external service
- Create a small Web API (in .NET 6 or above).
- Let it generate and return the signed JWT token.
- Call it from Creatio using HTTP request.

Show all comments
