i am trying to add a dropdown data by calling a webservice

does anyone have some advice?



Like 1

Like

0 comments
Show all comments

Hello

When creating a Web Service, the URI is embedded in the configuration and cannot be set with a System Setting like the values of the request parameters.

Usually the endpoints of the customer to integrate are located in "production" and "test" environments.

In Creatio if we need to integrate with the customer's web services we need two web service object: one for "test" and one for "production".

Why don't you allow the Web service configuration to set the URI with a System Setting thus there can be only one Web service object that automatically "points" to the proper customer's environment just changing the related system setting?

Thanks

4 comments

I completely agree. When using web services, the username and password (or API key etc) is already stored in the system settings. I would love for the setup/config instructions to only have one place users need to go to set up the values (in the system settings). As it is now, users have to go to the system settings to add those values, but then to the web services to add the URL.

Ryan

Ryan Farley,

Hello Ryan

If the web service is part of a package we create and deploy for our customer, the Web Service is "read-only" on the customer's platform then it's not possible to change the URL. That's why I'm asking to let this field to be set also from System Settings and not only manually.

Massimiliano



Massimiliano Mazzacurati,

It is still possible to change the URL of the web service, even if the web service is located in a locked/installed package. That is the one value it allows changing.

Ryan

Hello.

Thank you for your feedback. We completely agree that this is a very useful and much-needed functionality. Our development team already has a registered task to implement it, and based on your input, we have raised its priority to highlight its importance.

At the moment, the task is still in development, so we are unable to provide a specific ETA for its release.

Best regards,
Antonii.

Show all comments

Hi Everyone,

There is a sub process inside a main process, in which a web service (REST) is called but it is getting stuck due to operation timeout error (screenshot pasted). Our customer requested to bypass it if it is operation timeout so we checked that checkbox (Run current element in the background) in the subprocess. We thought that the main process now will not stop its execution even if the sub process stuck in the error state. But it is not and the main process is still stucking and not moving forward.

1. Following is the screenshot of the execution diagram of the main process where it got stuck at the subprocess -



2. Following is the screenshot of the subprocess where the web service is called.

3. Following is the screenshot of the error message -



Can anyone please suggest how to handle this situation?

Thanks in advance.

Like 0

Like

3 comments

Sadly, there's no way to handle the timeout error in the process, it will only put the process in an error state - I do wish it was an option to handle that in the process rather than have the whole process error.

Only option would be to increase the timeout for the web service call to possibly allow for the additional needed time. Otherwise, I've added script tasks that check for the service availability and can branch as needed to avoid the web service call, but that defeats the benefits of using the no-code web service components in the first place.

Ryan

Ryan Farley,

Thank you, if possible can you please share an example of how did you added script tasks that check for the service availability?

AS,

It was basically just C# that called one of the API methods and then set a param in the process so it knew to proceed or branch elsewhere. How that would look would depend on the API, but essentially you’re just writing code to call the API directly.

Show all comments

Hi Community,



We have this requirement, where we need to receive a complex json object and then store it in our database as a string, without using DataContracts.



To achieve this we though about using the "object" type and then serialize it into a string using JsonConvert.SerializeObject method.



	  [OperationContract]
	  [WebInvoke(Method = "POST", UriTemplate = "/store", RequestFormat = WebMessageFormat.Json, BodyStyle = WebMessageBodyStyle.Bare, ResponseFormat = WebMessageFormat.Json)]
      public Response AddStore(object store) {

         Response response = new Response();
         response.MessageId = "1";
         response.Description = "Store Inserted!";

        string storeString = JsonConvert.SerializeObject(store, Formatting.Indented);

        var ins = new Insert(UserConnection)
        .Into("ImdStagingInArticle")
        .Set("ImdMessage", Column.Parameter(storeString))
        .Set("ImdStateId", Column.Parameter(new Guid("2d1dee23-058b-45fe-95a0-2e1612fc4261")));

        ins.Execute();

        return response;
      }



However, the string is always empty.



Since the json is to complex, the serializer cannot process the entire json data.



We also tried to use WebOperationContext, but that doesn't work.



Can someone help us solve this issue? Did anyone have something similar?



Thank you.

Like 0

Like

7 comments

Hi,



First of all you need to make sure that you can convert the object into a string in general. Like create a Visual Studio project, add the logic to convert the object into a string using JsonSerializer like



string jsonString = JsonSerializer.Serialize(myObject); Console.WriteLine(jsonString);



And see the result. After the number of tests find the way when the data you pass is converted into the string and then start developing an additional logic of storing this data in the Creatio database using the insert query you used.



Alternatively find the way to make the object to have a constant set of keys so to be sure it will be converted to the string as needed.

Oleg Drobina,



After some changes I got it to work, by reading the raw body before the automatic parsing. However, this is working only on our Linux environment. As for for windows environment (Creatio Cloud), we are receiving some parse errors.



      [OperationContract]
      [WebInvoke(Method = "POST", UriTemplate = "/article", RequestFormat = WebMessageFormat.Json, BodyStyle = WebMessageBodyStyle.Bare, ResponseFormat = WebMessageFormat.Json)]
      public Response AddArticle(string articleJson) {

        string result = "";
        Stream inputStream = HttpContext.Current.Request.Body;

        inputStream.Position = 0;
        using (StreamReader reader = new StreamReader(inputStream, Encoding.UTF8))
        {
            result = reader.ReadToEnd();
        }

        var parsedJson = JsonConvert.DeserializeObject(result);
        string jsonString = JsonConvert.SerializeObject(parsedJson, Formatting.Indented);





        Response response = new Response();
        response.MessageId = "1";
        response.Description = "Article Inserted!";



        var ins = new Insert(UserConnection)
        .Into("ImdStagingInArticle")
        .Set("ImdMessage", Column.Parameter(jsonString))
        .Set("ImdStateId", Column.Parameter(new Guid("2d1dee23-058b-45fe-95a0-2e1612fc4261")));
        ins.Execute();

        inputStream.Close();

        return response;
      }



What could be the cause for such weird behaviour?



Thank you.




Pedro Pinheiro,



Well, it shouldn't happen. Maybe there is still some difference in the content we pass in the local machine and in the Windows machine?

Oleg Drobina,



The requests are the same for both local and cloud environments, except the address and credentials.



However, when I execute the request on the cloud environment I get this error:



 <p class="heading1">Request Error</p>
       <p>The server encountered an error processing the request. The exception message is 'This method or property is
           not supported after HttpRequest.GetBufferlessInputStream has been invoked.'. See server logs for more
           details. The exception stack trace is: </p>
       <p> at System.Web.HttpRequest.get_InputStream()
           at Terrasoft.Configuration.ImdArticleAPI.ArticleAPI.AddArticle(Object article)
           at SyncInvokeAddArticle(Object , Object[] , Object[] )
           at System.ServiceModel.Dispatcher.SyncMethodInvoker.Invoke(Object instance, Object[] inputs, Object[]&amp;
           outputs)
           at Terrasoft.Web.Common.ServiceModel.ThreadContextInitializer.Invoke(Object instance, Object[] inputs,
           Object[]&amp; outputs)
           at System.ServiceModel.Dispatcher.DispatchOperationRuntime.InvokeBegin(MessageRpc&amp; rpc)
           at System.ServiceModel.Dispatcher.ImmutableDispatchRuntime.ProcessMessage5(MessageRpc&amp; rpc)
           at System.ServiceModel.Dispatcher.ImmutableDispatchRuntime.ProcessMessage11(MessageRpc&amp; rpc)
           at System.ServiceModel.Dispatcher.MessageRpc.Process(Boolean isOperationContextSet)</p>



Have you encountered something similiar? What could be the cause for such error?



Thank you.



Pedro Pinheiro,



Creatio doesn’t know how to serialize/deserialize object. If you change object to string in Response AddStore(object store) you will be able to parse it with JsonParser of your choice.

Kirill Krylov CPA,



The problem is, if I change it to string I can only send strings to this endpoint (The Json must be converted to a string). Because, if I try to send a Json Object I get "400 Bad Request".







Hello everyone,



I managed to get it working by receiving the body as a Stream instead of a String.



With this solution, I don't get the "400 Bad request" and I can process any Json object.



I don't know if this is the best solution, but it's working for now.


	  [OperationContract]
      [WebInvoke(Method = "POST", UriTemplate = "/article", RequestFormat = WebMessageFormat.Json, BodyStyle = WebMessageBodyStyle.Bare, ResponseFormat = WebMessageFormat.Json)]
      public Response AddArticle(Stream requestBody) {

        string result = "";

        using (StreamReader reader = new StreamReader(requestBody, Encoding.UTF8))
        {
            result = reader.ReadToEnd();
        }

        var parsedJson = JsonConvert.DeserializeObject(result);
        string jsonString = JsonConvert.SerializeObject(parsedJson, Formatting.Indented);

        Response response = new Response();
        response.MessageId = "1";
        response.Description = "Article Inserted!";

        var ins = new Insert(UserConnection)
        .Into("ImdStagingInArticle")
        .Set("ImdMessage", Column.Parameter(jsonString))
        .Set("ImdStateId", Column.Parameter(new Guid("2d1dee23-058b-45fe-95a0-2e1612fc4261")));
        ins.Execute();

        return response;
      }



Feel free to give any feedback on this solution.



Thank you.



Show all comments

Hey,

I have followed all the steps in Implement a custom web service that uses anonymous authentication | Creatio Academy



Note:  Using Local Creatio Env, Creation:Energy 8.2v



`UsrAnonymousConfigurationService` File




Error: Internal Server Error

Like 0

Like

4 comments

Hello,



Please recreate the error and check both the Error.log file in the application logs (located at C:\Windows\Temp\Creatio by default) and the Windows events viewer logs to see the actual error message. This can be returned in case the services.config file was setup incorrectly or because of the incorrect setup in the Terrasoft.WebApp/Web.config file.

There might be an issue in the web.config file at the following line: `<add key="AllowedLocations" value="[Previous values];ServiceModel/UsrAnonymousConfigurationService.svc" />`.



I’m not sure what values should replace [Previous values].

Hello!



This issue might occur due to not enough setup in web.config on how to set it you can read here - https://academy.creatio.com/docs/8.x/dev/development-on-creatio-platform/back-end-development/web-services/web-service-implementation/examples/web-service-anonymous-authentication#title-2145-4



Especially check 4-6 it must help you here.

Still not working.

Looking for response

Show all comments

why i get this error. i use update
... 0/odata/Contact(guid'123') to change number value

Like 0

Like

1 comments

Hello,

The error you encountered, according to the analysis, was caused by the fact that the OData protocol takes some time to initialize. During this time, requests via the protocol may return an error. However, within 5 minutes of the request, the system successfully initialized the protocol.


Best regards,
Orkhan

Show all comments

Hi everyone,

I’m working on a custom web service and tried integrating Npgsql. After encountering a "no namespace found" error, I took the following steps:

  1. Added the Npgsql.dll file to the Tearsoft.web/bin directory.
  2. Modified the web.config file with the following binding redirect:

    xml


  3. <dependentAssembly>
        <assemblyIdentity name="Npgsql" publicKeyToken="5d8b90d52f46fda7" culture="neutral" />
        <bindingRedirect oldVersion="0.0.0.0-8.0.5.0" newVersion="8.0.5.0" />
    </dependentAssembly>
  4. Restarted the IIS server.
  5. Flushed Redis via the Clio CLI.

After these steps, I'm now facing the following error: Could not load file or assembly 'System.Data.Common, Version=6.0.0.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a' or one of its dependencies. The system cannot find the file specified. (Screenshot attached for reference)

I've already checked assembly binding logging, but I’m unsure how to resolve this error. Any suggestions or help would be appreciated!


Additional Context:

  • Working with PostgreSQL using Npgsql in the custom web service.
  • I made changes to the web.config file after adding the Npgsql DLL.


    this is the current state for my local instance .


Thanks in advance!

Like 0

Like

1 comments

Hi,

This issue requires a deeper analysis, and we advise you to create a case for Creatio support.

Thank you!

Show all comments

Hi Creatio Community,

I am working on extending the existing implementation of the Execute method in the web service designer, which is part of a base package in Creatio. My goal is to modify the method to add additional functionality: specifically, I want to save the web service response as a record using an EntitySchemaQuery (ESQ), so that the response can be displayed in a custom section inside Creatio.

However, I am encountering a compilation error:

Error:
cannot convert from 'System.Collections.Generic.IEnumerable<Terrasoft.Configuration.ServiceSchemaParameter>' to 'System.Collections.Generic.IEnumerable<Terrasoft.Configuration.ServiceSchema.ServiceSchemaParameter>'

It appears that the system is having difficulty converting between two types that have the same name but are possibly from different namespaces. I am using ServiceSchemaParameter in my custom implementation, but the IServiceSchemaClient.Execute() method is expecting the parameter to be of a slightly different type.

Here’s an overview of my approach:

  1. I've modified the Execute method to include an ESQ that logs the web service call and stores the response.
  2. The issue arises when passing the parameters (of type List<ServiceSchemaParameter>) to the Execute method, where it's expecting IEnumerable<ServiceSchema.ServiceSchemaParameter>.
  3. I believe the conflict is due to namespace ambiguity or mismatched types between base and custom implementations.

    My code:

  4. namespace Terrasoft.Configuration
    {


        using System;
        using System.Linq;
        using System.Collections.Generic;
        using System.Runtime.Serialization;
        using System.ServiceModel;
        using System.ServiceModel.Web;
        using System.ServiceModel.Activation;
        using Terrasoft.Core.Factories;
        using Terrasoft.Services;
        using Terrasoft.Web.Common;
        using Terrasoft.Core;
        using Terrasoft.Core.Entities;
        using Terrasoft.Configuration.ServiceSchema;

    	#region Class: CallServiceSchemaService

    	[ServiceContract]
    	[AspNetCompatibilityRequirements(RequirementsMode = AspNetCompatibilityRequirementsMode.Required)]
    	public class CallServiceSchemaService : BaseService
    	{
    		#region Methods: Public

    		[OperationContract]
    		[WebInvoke(Method = "POST", RequestFormat = WebMessageFormat.Json, BodyStyle = WebMessageBodyStyle.Wrapped,
    			ResponseFormat = WebMessageFormat.Json)]
    		public CallServiceSchemaResponse Execute(string serviceName, string methodName, List<ServiceSchemaParameter> parameters) {
    			if (parameters == null) {
    				parameters = new List<ServiceSchemaParameter>();
    			}
    			try {
    				UserConnection.DBSecurityEngine.CheckCanExecuteOperation("CanManageSolution");

    				// Getting the builder and client from the ClassFactory
    				var builder = ClassFactory.Get<IServiceSchemaParameterBuilder>();
    				var serviceSchemaClient = ClassFactory.Get<IServiceSchemaClient>();

    				// No need to cast, List<T> already implements IEnumerable<T>
    				var serviceResponse = serviceSchemaClient.Execute(UserConnection, serviceName, methodName, builder.Build(parameters.AsEnumerable()));

    				// Log the request and response
    				LogWebServiceCall(serviceName, methodName, parameters, serviceResponse);

    				return new CallServiceSchemaResponse(serviceResponse);
    			} catch (Exception e) {
    				return new CallServiceSchemaResponse(e);
    			}
    		}

    		#endregion

    		private void LogWebServiceCall(string serviceName, string methodName, List<ServiceSchemaParameter> parameters,
                IServiceClientResponse response = null, Exception error = null) {
                var entitySchema = UserConnection.EntitySchemaManager.GetInstanceByName("UsrWebServiceLog");
                var assignersEntity = entitySchema.CreateEntity(UserConnection);
                assignersEntity.SetDefColumnValues();

                assignersEntity.SetColumnValue("UsrServiceName", serviceName);
                assignersEntity.SetColumnValue("UsrMethodName", methodName);
                // Log additional columns if needed, as seen in your commented code
                assignersEntity.Save();
            }

    	}

    	#endregion

    	#region Class: CallServiceSchemaResponse

    	[DataContract(Name = "CallServiceSchemaResponse")]
    	public class CallServiceSchemaResponse : ConfigurationServiceResponse
    	{
    		#region Constructor: public

    		public CallServiceSchemaResponse(IServiceClientResponse serviceResponse) {
    			StatusCode = serviceResponse.StatusCode;
    			Success = serviceResponse.Success;
    			ResponseBody = serviceResponse.Body;
    			ResponseRawData = serviceResponse.RawDataResponse;
    			RequestBody = serviceResponse.RequestBody;
    			RequestRawData = serviceResponse.RawDataRequest;
    			ParameterValues = Newtonsoft.Json.JsonConvert.SerializeObject(serviceResponse.ParameterValues);
    		}

    		public CallServiceSchemaResponse(Exception e) : base(e) {}

    		#endregion

    		#region Properties: Public

    		[DataMember]
    		public int StatusCode;

    		[DataMember]
    		public string ParameterValues;

    		[DataMember]
    		public string RequestRawData;

    		[DataMember]
    		public string RequestBody;

    		[DataMember]
    		public string ResponseRawData;

    		[DataMember]
    		public string ResponseBody;

    		#endregion
    	}

    	#endregion

    	#region Class: ServiceSchemaParameter

    	[DataContract]
    	public class ServiceSchemaParameter
    	{
    		#region Properties: Internal

    		[DataMember(Name = "code")]
    		public string Code;

    		[DataMember(Name = "value")]
    		public object Value;

    		[DataMember(Name = "nested")]
    		public List<List<ServiceSchemaParameter>> NestedParameters;

    		#endregion
    	}

    	#endregion
    }



Request:
Could anyone guide me on how to properly resolve this type conversion issue? If there is a better way to manage the namespace or cast the types correctly, I would appreciate any advice or best practices to ensure compatibility between the types.

Thank you for your help!

Code Context:
CallServiceSchemaService.svc
Service Designer Package

Looking forward to your suggestions and insights!

Like 2

Like

1 comments

Hello Pranshu Basak,

Please change the part of the code

var serviceResponse = serviceSchemaClient.Execute(UserConnection, serviceName, methodName, builder.Build(parameters.AsEnumerable()));

to the new one:

var serviceResponse = serviceSchemaClient.Execute(UserConnection, serviceName, methodName, builder.Build((IEnumerable&lt;ServiceSchema.ServiceSchemaParameter&gt;)parameters.AsEnumerable()));

for solving the compilation error.



Show all comments

Hello.



I'm doing an Web services to send a document to sign, the api request the Url of the document so I'm using the following link https:[creatio instance]/0/rest/FileService/GetFile/70ec5d9f-a55e-4f5c-8f59-30d2c5149c4a/ef68e95e-ef77-eddf-dfa8-685557ee4875



70ec5d9f-a55e-4f5c-8f59-30d2c5149c4a correspons to the  UId from the SysSchema table where the attachments are stored and the ef68e95e-ef77-eddf-dfa8-685557ee4875 is the Id of the attachment. This URL allows me to dowloand the document to my computer, so I know that is the right link but when I used it in the web service it says that there is no document.



The json of the request is the following

{

    "url_doc": {

        "url": "https://151929-crm-bundle.creatio.com/0/rest/FileService/GetFile/70ec5d9f-a55e-4f5c-8f59-30d2c5149c4a/ef68e95e-ef77-eddf-dfa8-685557ee4875",

        "name": "Contrato.pdf"

    },

    "stickers": [

        {

            "authority": "Vinculada a Correo Electronico por Liga",

            "stickerType": "line",

            "dataType": "email",

            "email":"laura@artica.digital",

            "data": "laura@artica.digital",

            "imageType": "stroke",

            "page": 0,

            "rect": {

                "lx":74.88173,

               "ly":312.32596,

               "tx":196.9875,

               "ty":373.37885

            }

        }

    ]

}



When I sent the request the response is



{
    "error": "No document"
}



I had try this request with a Dropbox URL and works fine but I need to send the documents that are generated by the Word Reports. That why I'm trying to get the document from Creatio using the URL the API also gives me the option of sending the document using base64 but I dont know how to convert the file easly.



Can you help me please to know what is happenig?

Thank you

Like 0

Like

4 comments

The reason why this isn't working is because FileService/GetFile requires authentication to read. This is not an anonymous endpoint. The receiver of this, where ever you're sending this URL of the document to, is actually getting a 401 Unauthorized.

You'd have to either go the route of sending the base64 of the file, or expose an anonymous service in Creatio to provide the file to the other service.

Ryan

Ryan Farley,

Thank you, can you explain me please how can I convert the file to base64 please, I had see some examples but I not sure if I can do it using a script task in a business process or a source code

Laura Jurado,

The code would look something like this (not tested, but this should get you started). For this, I have two process params, one a uniqueidentifier AccountFileId (an Id of an account file) and second an unlimited text AccountFileBase64. The script task would look something like this:

var fileId = Get&lt;Guid&gt;("AccountFileId");

var entity = UserConnection.EntitySchemaManager.GetInstanceByName("AccountFile").CreateEntity(UserConnection);
if (entity.FetchFromDB(fileId))
{
    var base64FileData = Convert.ToBase64String(entity.GetBytesValue("Data"));
    Set("AccountFileBase64", base64FileData);
}

Ryan

Ryan Farley,

Thank you very much. It helped me a lot

Show all comments

I am connecting a third-party API to Creatio, it delivers different types of data including this:
"user_id": [
60,
"Luismary Mendez"
]
In the parameters of the Creatio response I have set it as an Array Text and as an Object



But when I try to connect this variable to the process it does not display it in the list of possible result values.

The field is Vendedor:

Like 0

Like

5 comments

This is because the user_id is an array in the payload received from the web service, not just a single value. If you know the array will only contain a single set of values and the first value in the user_id array will always be the integer Id and the second value will always be the text name, you could flatten them out by mapping them as text and integer values:

  • Map ID as: user_id[0]
  • Map Name as: user_id[1]

Ryan

Ryan Farley,

What you're telling me is that I have to set the user_id as an object?

You could, but that doesn't pass to a subprocess (with an array inside an array). If you are able to flatten it out and if you know the array will only contain a single set of values and the first value in the user_id array will always be the integer Id and the second value will always be the text name, that will pass easily to a subprocess. Like this for the "user_id" first element in array, which is an int from what you've shared:

The second value in the user_id array, which is a string from what you've shared, would look like this:

This is assuming your JSON looks like this:

{
	"result": [
		{
			"id": "someid",
			"name": "somename",
			"user_id": [
				60,
				"Some name"
			]
		}
	]
}

You're basically changing it from an array with an int in index 0 and string in index 1 to flattened out properties pointing to the value in index 0 and index 1. This is, of course, assuming that the user_id array will only contain an int at index 0 and a string at index 1.

Ryan

Ryan Farley,

Thanks Ryan, I understood your explanation, I will apply it and let you know how it goes.

Carlos Soto,

Thanks Ryan. It's works

Show all comments
