Which ports are needed for Infinity X?

Infinity 4 platform ports:

  • TCP port 274 - required for connecting workstations to the server
  • TCP port 275 - required to connect the Server Management utility to the Infinity Guardian service
  • TCP ports 20, 21 - necessary for the operation of the integrated FTP server
  • TCP port 277 - used to send faxes
  • TCP port 3050 is used to connect to the Firebird database.

Infinity also requires ports that are used by IP nodes. This includes the main port, which uses the IP node and the range of ports that are used dynamically during the process of establishing VoIP connections and for transmitting voice messages.

Basic ports for SIP telephony are 5060 and 5061.


Infinity X Ports:

All ports can be configured in the settings. Below are the default ports:

  • 10000 - to connect the server to the DBMS
  • 10010 - to connect the client to the server
  • 10019, 10020 - for connecting to Infinity 4
  • 10040 - for connecting a browser to Infinity Guardian, as well as for automatically updating clients
  • 10101, 10102 - for client access to the media storage
  • 10103 port for playing recorded calls

The VoIP telephony can be configured in the settings.
